Heated Right Side Rear View Mirror for 2004-2014 Ford F-150

A Heated Right Side Mirror for the F-150

This is a heated, power-adjustable right side (passenger side) rear view mirror with power puddle lamp built for the 2004-2014 Ford F-150, cross-referenced to OE number 7L3Z17682AE. If your passenger side mirror is cracked, no longer folds or adjusts electrically, has stopped defrosting in cold weather, or the puddle lamp underneath has quit working, a direct-fit replacement mirror restores all of that in one part.

Why This Mirror Covers a Full Decade of F-150 Production

Ford kept the F-150's basic door and mirror mounting design consistent across this generation's long production run, even as trim levels and options packages evolved from year to year. Because the mirror's mounting bracket, wiring harness connector, and glass all share the same design throughout this span, a single mirror assembly with the same OE number covers trucks built as much as a decade apart, provided they were equipped with the same power, heated, and puddle lamp features from the factory.

Key Features

• Cross-referenced to OE numbers 7L3Z17682AE, FO1321369, 6118586F, and 12801753R
• Power-adjustable, heated mirror glass with puddle lamp
• Chrome finish, bolt-on attachment
• Built to factory specifications and tested for weather, swing, and vibration durability

Specifications

• Placement: Right, front (passenger side)
• Color/Finish: Chrome
• Features: Power adjustment, heated glass, puddle lamp
• Attachment type: Bolt-on
• Condition: New

Compatibility

Fits the 2004-2014 Ford F-150, right (passenger) side only. Because F-150 trucks from this generation were built with several different mirror configurations depending on trim and options, it's worth confirming your truck was originally equipped with power, heated, and puddle lamp features before ordering to guarantee an exact match.

Signs Your Mirror Needs Replacing

A failing power mirror on the F-150 typically shows up as glass that no longer adjusts electrically, a mirror that won't fold in or out on command, heating elements that no longer clear frost or fog from the glass in cold weather, or a puddle lamp that's dim or completely out. Because the mirror housing also takes regular exposure to road debris, car washes, and the occasional door-ding at parking lots, a cracked housing or chipped glass is another common reason drivers replace the complete unit rather than just one internal component.

Why Replace the Complete Mirror Assembly

The heating element, power motors, glass, and puddle lamp on this mirror are all integrated into a single housing rather than sold as separately serviceable parts, which is why replacing the complete assembly is the standard repair when any one of these functions fails. Starting with a new, factory-spec assembly means the glass, motor, heater, and lamp are all fresh and properly matched at once, avoiding the mismatched fit or wiring issues that can come from trying to source individual internal components separately.

Installation Notes

Replacing this mirror means removing the interior door panel trim covering the mirror's mounting bolts and wiring harness, disconnecting the electrical connector, unbolting the old mirror, and installing the new one in reverse order before reconnecting the harness and testing all functions. Because the mirror's wiring connector is typically a simple plug-and-play design, most of the job's time goes into carefully removing and reinstalling the interior trim panel without breaking any retaining clips, and working slowly around the panel's edges with a trim removal tool rather than a flat screwdriver will help avoid cracking the plastic clips that hold it in place.

Ordering Information

This mirror is in stock and ships ready to install. Our Shipping Information page covers current timelines, and our Warranty and Returns pages explain what to do if anything isn't right on arrival. Not sure this matches your F-150's original equipment? Our Request a Part page is the fastest way to confirm before you order.

Related Parts

This mirror is listed in our Ford collection, along with our Body & Exterior collection, where you'll find other exterior components for the F-150.
